Selec XT546
₹1,382.00
XT546 is a feature-rich timing relay designed for precise timing control and reliability.
The XT546 timing relay offers a comprehensive set of features, making it suitable for applications that require precise timing control. The dual LED display ensures accurate monitoring of both set values and elapsed time.
With its memory retention, multiple operating modes, and accurate timing, the XT546 is well-suited for scenarios where reliability and precision are essential.
The presence of 1 C/O SPDT relay contact enables the relay to control electrical circuits, adding to its flexibility and applicability.
In summary, the XT546 timing relay is a reliable solution for applications demanding precise timing control, accuracy, and ease of use. Its compact design, versatile features, and industry certification make it a suitable choice for automation and control panels.
- Description
- Additional information
Description
| Display Type | 7 Segment LED, Dual Display |
| Display Configuration | 3+3 Digits |
| Feature | Memory Retention |
| Relay Contact | 1 C/O SPDT |
| Range | 9.99 / 99.9 / 999sec, 9.59min sec, 99.9 / 999min, 9.59hr : min, 99.9 / 999 hr |
| Operating Modes | ON Delay / Interval / Cyclic ON First / Cyclic OFF First |
| Reset | Front, Remote, Power Interruption |
| Accuracy | ± 0.05% or 50 ms (Whichever Is Greater) |
| Counting Direction | Down |
| Supply Voltage | 85 to 270V AC , 24V AC / DC |
| Size | 48 x 48mm |
| Mounting Type | Panel Mount |
| Certification | CE |
Additional information
| Weight | 1 kg |
|---|
