Multispan TC-443 Single Output Fixed Input PID Controller
₹1,935.00
- Description
- Additional information
Description
This is Single Output Fixed Input PID Controller and the Model no is TC-443 . 3 + 3 Digit , 7 Segment LED Display . Fixed Input J Type . PID/ON-OFF
Auto /Self tuning
| Model Name/Number | TC-443 |
| Pannel Cutout(mm) | 45×45 |
| Input Sensor | J Type |
| Range | j (0°C to 600°C) |
| Output | (SSR Parallel to 1 Relay)+2 Relay (3 Relay 1C/O 5A, 230V AC resistive load) & SSR Drive O/P 12V DC,20mA) |
| Control Action | PID / ON-OFF (Configurable) |
| Accuracy | ±1% of FSD |
| Supply | 100 to 270V AC , 50/60HZ |
| Dimension(HxWxD) | 48x48x95 |
Usually dispatched within 4 working days
Warranty : 1 year cover { not valid if found fire burnt or damaged }
Additional information
| Weight | 1 kg |
|---|
