Multispan MPD-192/MPD Motor Protection Device
₹2,749.00
- Description
- Additional information
Description
This is Motor Protection Device and the model no is MPD-192.
Model Name/Number | MPD-192 / MPD-152 |
Pannel Cutout(mm) | 92×92 / Din rail mounting |
Input signal | 3 ∅ 4 Wire/3∅3 Wire |
Voltage | 50-520V AC(L-L),30-300V AC(L-N) |
output | 1 Relay (No-C-NC) 10A,230V AC (resistive load) / 1 Relay (No-C-NC) 10A,230V AC (resistive load) 2 relay (No-C)(with simultanous actuation) |
Parameter tripping facility | Over Current Under Current Short Circuit Lock rotor point Earth leakage(in MPD-19EL) Over Voltage Under Voltage Phase sequence Unbalance Over frequency Under Frequency Phase loss Neutral loss |
Accuracy | class 0.5 |
Supply | 100-270V AC(SMPS), 50/60Hz |
Dimension(HxWxD) | 96x96x52 / 75x55x110 |
Usually dispatched within 4 working days
Warranty : 1 year cover { not valid if found fire burnt or damaged }
Additional information
Weight | 1 kg |
---|
