Multispan EPM-14 3 Phase Energy & Power Meter
₹2,588.00
- Description
- Additional information
Description
This is Multi-function meter and the model no is EPM-14. Voltage and Current input . CT Selectable up to 4000/5 . 1 Relay for Set KW
| Model Name/Number | EPM-14 |
| Pannel cutout | 92×92 |
| Input signal | 3∅4 Wire |
| Voltage | 30 to 300V AC(L-N)/50 to 520V AC(L-L) |
| Current | 5/5 to 6000/5A AC CT Ratio Selectable |
| Reset | KWH Reset By front key |
| Measuring Range | 0.000 to 9999 KW (Active power) 0 to 99999999 KWH (Active Energy) |
| accuracy | class 1.0 |
| Supply | 100 to 270V AC (SMPS), 50/60Hz |
| Dimension (HxWxD) | 96x96x54 |
Usually dispatched within 4 working days
Warranty : 1 year cover { not valid if found fire burnt or damaged }
Additional information
| Weight | 1 kg |
|---|
