Multispan BC-1046D Batch Counter
₹1,609.00
- Description
- Additional information
Description
This is Batch Counter and the Model no is BC-1046D . Batch counter in all sizes 96x 96, 72x 72, 48x 48 panel mount . 6+4 Digit , 7 segment LED . NPN/PNP Proxy , Micro-switch,
Auto/Manual reset . Up to 2 set point , 2 relay . Memory retention . Buzzer output
| Model Name/Number | BC-1046D |
| Pannel Cutout(mm) | 92×92 |
| Input | NPN/PNP Proximity switch/Micro Switch (Configurable) 230V AC Pulse (Factory set) |
| Range | Upper Display Range (0-999999 count) Lower display range(0-9999) |
| Output | 1relay+Buzzer |
| Reset | Auto reset/Manual reset |
| Memory | Non-Volatile Memory |
| Supply | 230V AC ±10%,50Hz |
| Dimension(HxWxD) | 96x96x42 |
Usually dispatched within 4 working days
Warranty : 1 year cover { not valid if found fire burnt or damaged }
Additional information
| Weight | 1 kg |
|---|
