HUMIDITY AND TEMPERATURE DATA LOGGER USING USB FLASH PEN DRIVE MODEL CT700

Description

Features :

1. Data saved directly on USB Pen drive in an MS Excel compatible file.
2. Separate displays for humidity and temperature
3. Capacitive Sensor (Dry/Wet available on request) for humidity and PT100 sensor for temperature.
4. Rate of logging settable by user in Mins: secs
5. Internal Real Time Clock with battery backup for saving values along with Date and Time.
6. No need of any complicated or additional software for managing data.
7. Saving data on Pen drive allows a very large amount of storage space at very low cost.



Specifications

1 . Display : 0.56″ Red LED display for humidity
0.56″ Red LED display for temperature
2. Display Range : 0-95% for relative Humidity and 0-50°C for temperature

3. Logging Rate : 1 second to 99Mins59seconds

4. Data logging : Directly create a .csv file on the pen drive(compatible with excel) giving a tabular format caules of Date, Time , humidity and temperature.

5. Sensor : Capacitive for Humidity(Dry/Wet sensor also available on request) PT100 sensor for temperature

6. Accuracy : ±2% ±1 least Significant Digit for Humidity.
± 0.2°C± 1 least significant Digit for temperature

7. Power Supply : 230V AC±15% at 50/60Hz

8. Mounting Type : Panel Type

9. Front Facia : 96mm x 96mm



DISPATCH : WITHIN 4 WORKING DAYS

Additional information

Weight	5 kg
