Multispan DPI-122 Dual Process Indicator
₹2,333.00
- Description
- Additional information
Description
This is Dual Process Indicator and Model no is DPI-122 . sizes 96 x 96panel mount , 4+4 Digit , 7 Segment LED Display , Dual Display , 2- Channel Input – Analog / PT-100-3W , Up to 2 Relay
24V DC transmitter power supply.
Model Name/Number | DPI-122 |
Pannel Cutout(mm) | 92×92 |
Input | PT-100 3 wire/4-20mA DC/0-20mA DC/0-10DC (Any Two Factory Set) |
Range | -999 to 9999 Analog I/P, PT-100(0.0°C – 400.0°C) |
Output | 1 Relay / 2 Relay (optional) 24V DC Transmitter Supply@30mA (Optional) RS-485 Modbus (Optional) |
Supply | 100-270V AC, 50/60 Hz |
Accuracy | ±1% of FSD |
Control Action | ON-OFF |
Dimension(HxWxD) | 96X96X52 |
Usually dispatched within 4 working days
Warranty : 1 year cover { not valid if found fire burnt or damaged }
Additional information
Weight | 1 kg |
---|
